AISI P20 Plastic mold steel P20 steel plate forging module

Original price was: $1.66.Current price is: $1.36.

1、Latest Price of AISI P20 Plastic mold steel P20 steel plate forging module :

Steel grade Thickness die steel blank/ raw material Bright plate/light plate Precision material plate Origin Delivery Status
P20 steel forging module 280-590mm USD 1.36/KG USD 1.98/KG USD 1.98/KG China HRC:30-38

2、Steel grade characteristics of AISI P20 Steel plate:

The Plastic mold steel AISI P20 Steel is Pre hardened to HRC30-38, no heat treatment required, never deformed, suitable for electrical discharge machining, easy to polish.

3、Application of AISI P20 Steel plate:

Injection molds and blow molds for thermoplastic materials.

4、chemical composition of AISI P20 Steel plate:

C Si Mn P S Cr Mo
0.35-0.45 0.20-0.40 1.30-1.60 ≤0.035 ≤0.035 1.80-2.10 0.15-0.25

Description

1、Latest Price of AISI P20 Plastic mold steel P20 steel plate forging module :

Steel grade Thickness die steel blank/ raw material Bright plate/light plate Precision material plate Origin Delivery Status
P20 steel forging module 280-590mm USD 1.36/KG USD 1.98/KG USD 1.98/KG China HRC:30-38

2、Steel grade characteristics of AISI P20 Steel plate:

The Plastic mold steel AISI P20 Steel is Pre hardened to HRC30-38, no heat treatment required, never deformed, suitable for electrical discharge machining, easy to polish.

3、Application of AISI P20 Steel plate:

Injection molds and blow molds for thermoplastic materials.

4、chemical composition of AISI P20 Steel plate:

C Si Mn P S Cr Mo
0.35-0.45 0.20-0.40 1.30-1.60 ≤0.035 ≤0.035 1.80-2.10 0.15-0.25

5、physical property  of SAE/AISI Astm P20 steel plate:

P20 Critical temperature of steel:

Critical point Ac1 Ac3 Ar1 Ar3 Ms Mf
Temperature/℃ 770 825 640 755 335 180

6、Available specifications of P20 Steel plate:



P20 Die steel blank raw material:Thickness 10-800mm×Width 20-2200mm×Length 20-6000mm

Light panel/heat treated light panel/polished double-sided light panel: thickness 10-600mm x width 20-2000mm x length 20-3000mm

Fine material: thickness 10-600mm x width 20-2000mm x length 20-2200mm

7、Delivery standards for AISI P20 steel plate:

Definition of raw material: The original factory shipped state refers to the surface with oxide scale, the flat material has saw cut surfaces on all four sides, and the carbon plate may have fire cut surfaces, with tolerances according to delivery standards;

Definition of Light Plate: Refers to rough milling on all four sides and fine grinding on the top and bottom;
Definition of precision material: Refers to four side precision milling and two large surface grinding machines for precision grinding.
